Quality Certification:
Feature and specification:
Product Specifications
Operating conditions:
• Ambient temperature: 5 °C ~ 40 °C
• Relative humidity: 20% ~ 90%
• Range of atmospheric pressure: 700hPa ~ 1060hPa
• The syringe pump shall be operated in the environment free from strong compact, vibration, water & other liquid penetrating into the unit, and corrosive gas.
Transportation and storage conditions:
• Ambient temperature: -40 °C ~ + 60 °C
• Relative humidity: # 90%
• Range of atmospheric pressure: 700hPa ~ 1060hPa
Overall dimension: 308mm (length) 144mm (width) 156mm (height)
Net weight : 2.2Kg
Speed :
50 ml syringe : 0.1 ml/h ~ 1200 ml/h (0.1 ml/h each level)
30 ml syringe : 0.1 ml/h ~ 600 ml/h (0.1 ml/h each level)
20 ml syringe : 0.1 ml/h ~ 400 ml/h (0.1 ml/h each level)
10 ml syringe : 0.1 ml/h ~ 300 ml/h (0.1 ml/h each level)
5 ml syringe : 0.1 ml/h ~ 100 ml/h (0.1 ml/h each level)
Speed accuracy: the error of infusion speed shall not exceed ± 3%
Fast infusion:
1200 ml/h (50 ml syringe)
600 ml/h (30 ml syringe)
400 ml/h (20 ml syringe)
300 ml/h (10 ml syringe)
100 ml/h (5 ml syringe)
Total amount inquiry: 0.1 ml ~ 9999.9 ml (0.1 ml each level) Limited amount: 0.1 ml ~ 9999.9 ml (0.1 ml each level) Blockage alarm threshold:
• Low : 300mm ± 100 mmHg;
• Medium : 600 mmHg ± 100 mmHg;
• High : 900 mmHg ± 100 mmHg;
Alarm: Residual alarm, completed injection alarm, tubeblockage alarm, unclamped cylinder alarm, improperly
installed putter alarm, out-of-limit speed alarm, alarm of infusion equivalent to limited amount, disconnected power line alarm, battery power depletion alarm, system error alarm, neglected operation alarm. Power supply: AC 100-240 V, 50/60 Hz; in-built batery DC 11.1 V rechargeable lithium batery; the fully charged batery can sustain the pump operaaonor more than 3 hours at the speed of 5 ml/h (specified by EN 60601-2-24:1998 standard). Power: 15VA
Feature and specification:
More detail specification and parameter please ask our team for a brochure
• Pump comes with static mode for quick access on air cells inated & deated process, low/normal
pressure ident fication light, & pressure adjustable knob for setting comfortable pressure level.
• Provide with fixed hook for easy t to the bed & air lter to ensure comfortable pressure level
• Built in alarm reset wihch warn user for abnormal pressure situation
• Auto firm mode for nursing & caring convenience to automatically inate to max pressure level & return to user de ned pressure level after 30min
• Waterproof TOP COVER, vapor permeable cover provides a low friction surcafe.
• CPR features “Quick Air Release” in emergency situation.
• Matters come with changeable Air Cell witch easy to replace & clean.
• Come with “Quick connector” to facilitate the setup proccess.
Medical mattres ned to heal and prevent bed sore during recovery Stage I, II, III, IV*. It commonly used in hospital, nursering homes & rehabilitation center for reducing the incidence of bedsore while optimizing patient comfort s designed to heal and prevent bed sore during recovery Stage I, II, III, IV*. It commonly used in hospital, nursering homes & rehabilitation center for reducing the incidence of bedsore while optimizing patient comfort
Pump Technical Specifications:
Model No : Scorpio
Power supply : 220V/50Hz, 1A
Air output : 8~9 Liter/min.
Pressure range : 20 mmHg V~70 mmHg
Cycle time : 10/15/20/25 min.
Size : 28cm(L) x 20cm(W) x 10cm(H)
Weight : 2.5 kg
Other feature : Auto rm mode, alarm reset mode static mode
Mattress Technical Specifications:
Size. : 203cm(L) x 88cm(W) x 20cm(H)
Material : Nylon/pu with zipper
Air cell material : TPU
Base material : Nylon / PVC
Number of cells : 20
Max user weight : 180kg
Other features : CPR valve, pillow function, quick
connectors, transport function
